Bilstein B16 Clubsport (BCS) 2-Way – Coilover Suspension Kit for Toyota GR Yaris

The adjustable Bilstein B16 Clubsport (BCS) coilover suspension kit represents the pinnacle of German engineering applied to motorsport and track-day use for the Toyota GR Yaris. Developed specifically for competition and extreme circuit driving, this 2-way suspension system brings racing technology and expertise directly to the track.

Unlike road-oriented versions, the Clubsport range features independent 2-way damping adjustment. Dedicated adjusters allow the rebound and compression (bump) damping forces to be set separately and precisely. This flexibility enables drivers and suspension specialists to tailor the chassis setup to the circuit, tyre type (slick or semi-slick) and track-surface conditions.

Built using renowned high-pressure gas monotube technology in an upside-down configuration and finished with a premium corrosion-resistant coating, the kit provides maximum resistance to the sustained thermal loads encountered during track sessions. As a component designed solely for motorsport and track-day use, it does not include TÜV approval for road use.

Features

• Type: Adjustable motorsport / track-day coilover suspension kit (2-way coilover kit)
• Series: Bilstein B16 BCS (Clubsport)
• Damping adjustment: Independent 2-way adjustment (rebound and compression adjusted separately)
• Ride-height adjustment: Continuously threaded trapezoidal adjustment
• Damper technology: High-pressure gas monotube (monotube / upside-down technology)
• Springs and calibration: Track-specific spring rates and setup
• Approval: No TÜV approval (for track / motorsport use only)
• Manufacturer part number: 48 323864M0 / 48323864M0
• Dynamic performance: Virtually eliminates body roll and pitch, delivering outstanding traction and turn-in precision
• Durability: Surface treatment providing excellent protection against corrosion and wear

Note

This product is intended for sporting and competition use on closed circuits. Installation and subsequent suspension geometry adjustment should be carried out by a workshop specialising in competition suspension setups.
